Epoxy Pool Paint – AquaGuard 5000® Part A Only


Epoxy Resin Pool Resurfacing Product

AquaGuard 5000® Epoxy Pool Paint is a high performance, 100% solids, epoxy resin with exclusive alkali curing agents, reinforced with proprietary additives for physical strength.

AquaGuard 5000® is an epoxy resin pool paint formulated to be sprayed or roll applied to steel, concrete or fiberglass surfaces. It can be sprayed in a single coat application or roll applied in 2 or 3 (recommended) coats.

This is a two component system: Resin and Activator. One unit will cover 600-700 Sq. Ft.

Epoxy Swimming Pool Paint – AquaGuard 5000®


Epoxy Pool Paint

AquaGuard 5000® Epoxy Pool Paint is a high performance, 100% solids, epoxy resin with proprietary alkali curing agents.

AquaGuard 5000® is a non-porous surface coating. This product keeps the coated surface immune to rust, algae, chlorine or damage from other chemical reactants.  Because of this, once resurfaced with AquaGuard 5000®, most water and chemical stains are easily removed with light washing or scrubbing. Swimming pool owners who resurface with AquaGuard 5000® will have less maintenance, less chemical usage, and spend less time and money over time. AquaGuard 5000® Epoxy Pool Paint is not only a stylish surface coating that will restore lasting beauty to any pool, but also makes the pool easier to clean and maintain over time.

This product is not only for use in private or commercial swimming pools. AquaGuard 5000® is also FDA compliant to be safe for drinking water and may be used in surge tanks, ponds, fountains,and dive tanks as well.

Color Selection

AquaGuard 5000® is currently available in 7 beautiful solid finishes. This includes Pearl White and Ice Blue – both approved for use in commercial swimming pools because of their high levels of lightness and luminous reflectance. Florida Building Code 454.1.2.4 requires commercial swimming pool floors and walls to have the characteristic of reflecting instead of absorbing light.This is measured on a scale of Lightness (CIE L-value) and a wet Luminous Reflectance Value (CIE Y-value) as determined by American Standard ASTM D 4086, ASTM E 1477, ASTM E 1347. Our product not only meets, but exceeds required levels in both areas.

Our product improves swimming safety, especially for children. People standing outside the water, such as lifeguards and swimming pool supervisors are able to quickly identify swimmers who may be  in need of emergency intervention.

In addition to our 7 solid finishes, we also offer an exclusive Designer Series which artistically combines colors to add a depth of color and uniqueness to the surface while also camouflaging imperfections in the pool’s main structure.

Available Colors:

  • Standard Blue
  • Gulfstream Blue-Backordered
  • Pearl White
  • Miami Blue-Discontinued
  • Midnight Black
  • Stone Grey
  • Ice Blue

Designer Series

Our Designer Series Epoxy Pool Paint color selections add a depth of color and uniqueness while also camouflaging imperfections in the pool’s infrastructure. This includes osmotic blistering that may appear as a result of fiberglass wearing out over time. Homeowners can purchase our portable dot sprayer for DIY application.

Available Colors:

  • Aqua Brite
  • Aqua Gem
  • Aqua Diamond


AquaGuard 5000®  – Epoxy Pool Paint is:

  • Scratch resistant – it will not scratch or damage from repeated scrubbing or prolonged use
  • Resistant to chemical stains and algae – surfaces finished with AquaGuard 5000® requires less chemical maintenance, scrubbing and brushing
  • Formulated to adhere to Concrete, Steel and Fiberglass Surfaces
  • Great for homeowner DIY repairs to concrete and fiberglass surfaces – large and small repairs can be done easily and will last 10-15 years under warranty
  • A hard, non-porous, smooth surface similar to bathroom showers and tubs

Surface Preparation Requirements:

Before applying AquaGuard 5000®, Concrete surfaces will need to be acid washed and neutralized with a 50/50 solution of muratic acid and water. Surfaces may also need to be pressure washed, depending on the severity of surface damage. Concrete should be repaired and restored as necessary prior to application. Concrete and plaster surfaces require a sealer/primer for reconditioning prior to application.

Fiberglass will need be sanded down with a course grain emery disk to achieve an adequately smooth surface profile or anchor pattern prior to application. No additional sealer/primer is needed for fiberglass application.

AquaGuard 5000® is Resistant to 21 different chemicals including:

  • Chlorine
  • Acid
  • Salt Water
  • Gasoline


More related Data Bulletins

*Please Note: Color may vary from samples shown on our website.

Additional information

Weight 46 lbs
Dimensions 48 × 36 × 36 in
